HADA-4B500
HADA-4B500 is a 4x500W digital amplifier that supports low and high impedance loads. The internal DSP, through the DSP Manager software, allows tailoring the input and output signal through parametric EQs, multi-band compressors, limiters, and delays and each configuration can be saved as a preset. In addition to the software option, input levels can be controlled via the front panel potentiometers, via remote controls using the rear panel GPI, or via a TCP/IP from third party control systems. All HADA series amplifiers include efficient thermal protection, DC protection, over current protection, and HF protection for total reliability in any kind of installation.
| Number of output channels | 4 |
|---|---|
| Output connection type | 2-pin Euroblock |
| Output configuration | Lo-Z/Hi-Z, 70V/100V (Bridge mode), 4Ω/8Ω Output mode selection per channel/couple by software (Settings by HADA DSP Manager) |
| Number of input channels | 4 analogue input channels |
| Input connection type | Analogue: IN1-4: 3-pin Euroblock, balanced, pitch 3,5 mm |
| Input configuration | Digital matrix 4 in x 4 amp. out (Settings by HADA DSP Manager) |
