SAMI-612
SAMI-612 is an installation audio mixer in standard rack format, featuring 6 MIC/LINE Stereo inputs, 1 Stereo MIX input and 1 Stereo MAIN output + 1 Stereo REC output. Each input has a dedicated 3-band tone control, a feature which is fundamental to get a perfect microphone mix in an installation. Input 1 includes talkover (priority) function over the mix bus and additional front panel jack connector. Main output ST/MONO mode switch and MUTE port for external dry contact triggering.
| Number of input ports | 6, MIC/LINE ( 1 STEREO direct MIC input on front panel) 1, MIX LINE |
|---|---|
| Connection type | MIC: 3-pin Euroblock LINE/MIX: RCA |
| Input sensitivity | LINE 2-5: 0dB LINE 6: 0dB/-6dB (internally selectable) MIC 1-5 BAL: -35dB |
| Input sensitivity adjust | MIC/LINE: ±15dB |
| Input impedance | LINE 1-6: 50kΩ MIX LINE: 10kΩ MIC 1-6 BAL: >1kΩ |
| CMRR | MIC: >60dB @ 1 kHz |
| Phantom voltage | +18VDC |
SAMI-612
SAMI-612 is an installation audio mixer in standard rack format, featuring 6 MIC/LINE Stereo inputs, 1 Stereo MIX input and 1 Stereo MAIN output + 1 Stereo REC output. Each input has a dedicated 3-band tone control, a feature which is fundamental to get a perfect microphone mix in an installation. Input 1 includes talkover (priority) function over the mix bus and additional front panel jack connector. Main output ST/MONO mode switch and MUTE port for external dry contact triggering.
